LED POST TOP FIXTURES

BUILD TO ORDER

5 Year Warranty

LED POST TOP FIXTURE | 100 Watt | Slip Fitter Mount | CCT Tunable

SKU: GLL-GS02-100WFAT2F1-abcd

LED post top lamp fixture comes with an adjustable head for easy installation and shipping.  Slip fitter mount standard.

ORDERING GUIDE & EXAMPLE : GLL-GS02-100WFAT2F1-BRSP [100 Watt | Bronze Housing | Surge | Photocell]

GLL = Green Lighting LED |GS02 = Product Series | Wattage | F = FAHOLD Driver | A = Hongli Diodes | T2 = Viewing Optics | F1 = Version Number |
[a] housing color = [BH] black, [WH] white or [BR] bronze | [b] motion sensor = blank no motion or [MS] motion sensor |
[c] surge protector = blank no surge protector or [S] 10kv Surge Protector | [d] photocell = blank no photocell or [P] photocell

Additional information

Weight 14.3 lbs
Dimensions 17.7 × 17.7 × 23.6 in
BEAM ANGLE

TII 120°

CERTIFICATIONS

cULus, RoHS

CRI

>80

DIMMABLE

1-10V Dimming

LED TYPE

SMD2835 Hongli

INPUT VOLTAGE

100-277V; 50/60Hz

OPERATING TEMP

-40°F~122°F

POWER FACTOR

>0.9

THD

≤20%

WARRANTY

5 Years

WATERPROOF

IP65 Wet Location Rated

CCT

3000K~4000K~5000K CCT Adjustable / Tunable

LUMENS

11,800~12,800LM

BASE

Slip Fitter Base

HOUSING COLOR

[BH] black, [WH] white or [BR] bronze

SURGE PROTECTION

10KV
